Description

Cable Sheath Automotive Wire - 4MM

Our 4MM twin sheath automotive cable pure features a oxygen-free copper wire and reinforced PVC cover with black sheathing. The wire is waterproof, fire-retardant and can withstand extreme temperature changes without losing conductivity. It is designed to meet Australian standards and is SAA-certified.

Features:
* 4MM twin sheath automotive cable
* Oxygen-free copper core conductor
* Low eccentricity
* Reinforced PVC material
* SAA-certified
* RoHS
* Can normally work up to 450V AC/DC


Specifications:
* Conductor: Oxygen-free plain copper wire to AS/NZ 1125
* Insulation: V90 PVC to AS/NZ 3808
* Sheath: 5V90 PVC to AS/NZ 3808
* Amp rating: 22
* No. of cores: 2
* Cable Length: 30m
* Cable diameter: 4mm
* Strand no. diameter: 23/0.32mm
* Nominal area: 1.84mm2
* Nominal O.D.: 3.8mm x 6.3mm
* Colour: Black sheathing
* Conductor resistance <10.1O/Km(20?)
* Dielectric strength(kV/sec AC):2.5/60
* Unaged acceptable tensile strength = 12.5Mpa
* Unaged acceptable ultimate elongation =130%


Package Content:
1 x Twin Core Cable
1 x Cable Spool

Pickup & Delivery
  • You are most welcome to collect your order from our warehouse at 1/191 The Horsley Drive Fairfield NSW 2165 (Entry from Tangerine Street).
  • You need to place your order online first and make sure you have received confirmation that your order is ready for pick-up before coming in. Please note that we require up to 2-3 business days to process your order.
  • Free shipping is only available to select post codes and may not include certain far regional areas, to check eligibility enter post code into shipping calculator.
  • Provide us with your correct delivery address and contact details
  • Please make sure someone is at home from 7 am - 7 pm on the delivery day. if you believe an alternative address is more convenient to deliver the item then please make sure you change the address at eBay checkout.
  • Delivery guy will require an assistant to unload heavy items of his vehicle. Our delivery guys only deliver at property entrance on ground level.
  • We do not ship to PO boxes and surrounding islands.

For all metropolitan areas allow between 2-7 working days for delivery and for all non-metropolitan areas allow between 5-10 working days.

After ordering online, you will receive an email confirmation from Bargains Online containing your receipt of payment details (if you have provided your email address). We will also normally confirm receipt of your order soon after ordering.

Twin Core Wire Electrical Automotive Cable 2 Sheath 450V 4MM 30M

Don't Pay $104.00
$63.00
SAVE $41.00
  • In Stock
