TEF1109P-8-102W is a Tenda switch that offers 9 10/100M RJ45 ports. Ports 1-8 comply with the IEEE802.3af standard (maximum PoE power output : 15.4w) and 802.3at standard (maximum PoE power output: 30W). The switch offers a maximum PoE power output of 92W and can supply power to exchange data with APs, IP cameras, and IP phones through CAT5e cables. It also provides simple management modes such as Standard, VLAN. Thus, F1109P-8-102W is a perfect choice for SMBs, hotels, and office to have small-scale HD surveillance and wireless networking.
|Standard & Protocol||IEEE 802.3/IEEE 802.3u/IEEE 802.3x/IEEE 802.3af/IEEE 802.3at|
|LED indicator||9 × Link/Act per device|
1 × Power per device
|Interface||8 10/100Base-T ports(Data/Power)|
1 10/100Base-T ports(Data)
|Lightning Protection||6KV for uplink port|
|Store & Forward||Yes|
|exchange capacity||1.6 Gbps|
|Packet Forwarding Rate||1.34Mpps|
|MAC Address Table||2K|
|PoE supply management||Port 1-8 support IEEE802.3at/af PoE standard|
|PoE through pin||1 2 4 5 +|
3 6 7 8 -
|Input Voltage||AC: 100-240V~50/60Hz|
|Dimension||177.5 × 104 × 26mm ( W x D x H )|
|Port Features||Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.|
VLAN: ports 1 to 8 are isolated from each other, but can communicate with ports 9 (uplink port) respectively.
|Humidity||Operating Temperature: 0°C~40°C (32°F~104°F)|
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
1 x Tenda TEF1109P-8-102W 9-Port Fast Unmanaged Switch With 8-Port PoE
